Diesel motor
Lombardini LDW 903/1003 HP 21/24
Lombardini LDW 1204/1404 HP 29/33
Perkins 403C-11 HP28 diesel
Traction
Hydrostatic on 2 or 4 wheels
Gears
2 gears + neutral in central posotion – electrical control from control panel
Steering
with hydraulic power steering on the front wheels
Speed
min 0 km/h
max 15 km/h
Brakes
hydraulic on the rear wheels-parking/negative brake on 4 wheels
Platform One central collector with hydraulic lift (available size and vertical lift rails can be seen in the below diagrams)
Detachable footguard.
Front lift Hydraulic lift for loading bins up to 350 kg capacity
Rear lift Hydraulic motor for unloading bins up to 350 kg capacity
Roller rails for bins
Pruning equipment C.500 lt compressor – electromagnetic coupling, control on panel
The technical data are indicative and not binding.
